Technology
|
Microprocessor
|
|
Programs
Button:
Foot pedal:
|
Start-Stop with timer, 60 min
Standard (flame during pressed foot pedal, foot pedal optional)
|
|
Safety features
Safety Control System (SCS)
with gas safety cut off:
|
ignition and flame control, temperature monitor
burner head clogging monitor (BHC)
automatic unit switch off after 4h
|
|
Gas supply and consumption
Gas connection:
Gas types:
Connected load:
Continuous cartridge operation:
|
1/4” left with gas filter
II2ELL3B/P: natural gas E/LL,18 - 25 mbar
liquid gas, 47,5 - 57,5 mbar
43 g/h liquid gas, 49 l/h natural gas (LL)
CV 360 - 65 min
CG 1750 - 210 min
C 206 - 230 min
CP 250 - 305 min
CV 470 - 550 min
CV 270 - 280 min
|
|
Temperatures
Flame temperature:
Temperature threshold level:
|
1200 °C on liquid gas
1170 °C on natural gas (E)
0.55kW liquid gas, 0.50kW natural gas (E), 0.40kW natural gas (LL)
|
|
Electrical
Power consumption:
Power connection:
|
2 VA (stand by max. 0.1 VA)
100-240V / 50/60Hz / max. 0.3 A; 9V DC / 1.3A
Level 6 (stand by power consumption max. 0.1W)
|
|
Mechanical
Burner tube:
Measurements (w x h x d):
Height with burner tube:
Weight:
|
removable, stainless steel
89 x 34 x 88 mm
94 mm
385 g
|
|
Licenses
DIN-DVGW Reg.-No.:
CE:
EU guidelines:
|
NG-2211AS0167
EN 61326-1, EN61010-1, EN61010-2-010
2014/30/EU, 2014/35/EU, 2011/65/EU
|
